8-Slot Battery Swapping Cabinet

  • Model No.: BSC-08
  • Cabinet Dimension: 1585mm*735mm*600mm(H*W*D)
  • Slot Dimension: 220mm*260mm*400mm(H*W*D)
  • Screen Type: 10.1 inch touch screen
  • Communication: 4G, Wi-Fi, RS485, CAN
  • Input Voltage: 220VAC(Customizable)
  • Maximum Slot Charging Power: 750W(Customizable)
  • Battery Voltage: 48V/60V/72V

Multiple Protection

The cabinet are multiple protected with firefighting devices, water immersion devices, temperature sensors, smoke sensor devices, temperature control devices, surge protectors, etc.

Smart Charging

The cabinet conducts a real-time monitoring of the battery's internal voltage, temperature, and other status information, identify the battery problems and send warning messages to the maintenance staff.

User Friendly

Scan the code to complete the battery swapping process in 30 seconds, 10.1 inch touch screen with user friendly interface, each slot can customize bottom roller for easy battery swapping.

Nayo Tropical Technology M-Cloud Platform

Nayo Tropical Technology M-Cloud Platform is a comprehensive platform designed for efficient battery swapping operation, Web Page Management Platform and Mobile App(Andriod & iOS) are available.
